Place of Origin: | China |
Brand Name: | Upperbond |
Certification: | CE, ISO |
Model Number: | Maker |
Minimum Order Quantity: | 50 Pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Carton |
Delivery Time: | 5-8 days |
Payment Terms: | T/T, Western Union, MoneyGram |
Supply Ability: | 70000 pcs/month |
Cigarette Sizes: | King Size/ Super Slim / Nano | Thickness: | 0.5mm / 0.62mm |
---|---|---|---|
Sea Transportation: | Large Order Only | Sample: | Charged Only |
Optional Material: | Linen | Material: | Kevlar |
High Light: | MK8 Filter Machine Garniture tape,MK8 Glued Garniture Tape,Garniture Tape For MK8 |
14.5 * 3100 Glued Garniture Tape For Filter MK8 Cigarette Machine Parts
Garniture tape is used for cigarette making machines on format garniture sector to convey cigarette paper with tobacco wrapped in.We offer aramid tapes and Linen tapes.
Aramid Fibers
Aramid fibers are a class of heat-resistant and strong synthetic fibers. They are used in aerospace and military applications, for ballistic-rated body armor fabric and ballistic composites, in marine cordage, marine hull reinforcement, and as an asbestos substitute. The chain molecules in the fibers are highly oriented along the fiber axis. As a result, a higher proportion of the chemical bond contributes more to fiber strength than in many other synthetic fibers. Aramides have a very high melting point (>500 °C)
Structure And Properties
When Kevlar is spun, the resulting fiber has a tensile strength of about 3,620 MPa, and a relative density of 1.44. The polymer owes its high strength to the many inter-chain bonds. These inter-molecular hydrogen bonds form between the carbonyl groups and NH centers. Additional strength is derived from aromatic stacking interactions between adjacent strands. These interactions have a greater influence on Kevlar than the van der Waals interactions and chain length that typically influence the properties of other synthetic polymers and fibers such as .
Production
Kevlar is synthesized in solution from the monomers 1,4-phenylene-diamine (para-phenylenediamine) and terephthaloyl chloride in a condensation reaction yielding hydrochloric acid as a byproduct. The result has liquid-crystalline behavior, and mechanical drawing orients the polymer chains in the fiber's direction. Hexamethylphosphoramide (HMPA) was the solvent initially used for the polymerization, but for safety reasons, DuPont replaced it by a solution of N-methyl-pyrrolidone and calcium chloride. As this process had been patented by Akzo (see above) in the production of Twaron, a patent war ensued.
Specifications:
Machine Model | King Size | Super Slim |
MK8 / MK8D | 2489*21/22mm | 2489*14.0/14.5mm |
MK9 / MK95 | 2800*21/22mm | 2800*14.0/14.5mm |
Protos 70 / 80 | 3100*21/22mm | 3100*14.0/14.5mm |
Protos 90E | 3830*21/22mm | 3830*14.0/14.5mm |
Protos 2/P 2-2 | 3930*21/22mm | 3930*14.0/14.5mm |
Super 9 / Passim | 3135*21/22mm | 3135*14.0/14.5mm |
Decoufle | 3080*21/22mm | 3080*14.0/14.5mm |
GD 1-2-1 / 1-2-1 Plus | 2790*21/22mm | 2790*14.0/14.5mm |
KDF2 / ZL22 / ZL23 / ZL21 | 2715*18.5mm | 2715*12.5mm |
KDF1 | 3289*18.5mm | 3289*12.5mm |
